WATERAX offers a complete line of high performance portable centrifugal pumps.Striker-3 High-Pressure 3-Stage Fire Pump
100142
Striker-3 High-Pressure 3-Stage Fire Pump
100142
The STRIKER-II®-14V configuration is powered by a Briggs & Stratton 14 HP engine and vertical-drive unit in a vehicle mount configuration with a base mount and 8-pin FastWire connections.
Maximum pressure
345 PSI (23.8 BAR)
Maximum flow
102 US gals/min (386 L/min)
Maximum head
797’ (243 m)
87 GPM (329 lpm) @ 100 PSI (6.9 BAR)
75 GPM (284 lpm) @ 150 PSI (10.3 BAR)
40 GPM (151 lpm) @ 250 PSI (17.2 BAR)
Model and type
Briggs & Stratton, Vanguard 400 Series 4-cycle, horizontal shaft, single cylinder, OHV
Maximum Power
11.7 hp (8.7 kW) @ 3600 RPM
Maximum Torque
19.5 lb-ft (26.4 Nm) @ 2500 RPM
Starting System
12 VDC electric with manual recoil backup start
Type
Detachable 3-Stage Centrifugal Pump
Intake
2" Male NPSH
Discharge
1-1/2" Male NPSH
137 lbs (62 kg)
Base Mount with Industrial Isolators
Timing Belt and Pulley; Speed Increaser 1.88:1
Fuel Tank
Integral 1.6 US gallons (6.1 L) (Standard)
FastWire
3' CTRL Cable with 8 pin connector (Standard)
Controls
Remote Mount Control Panels - XCP Series (Optional)
